Input: Choose one of HDMI2.0×1, DVI(HDMI1.4)+DP1.1, DVI×1, 3G SDI×1

Output: Gigabit network port ×8, HDMI2.0 LOOP×1, AUDIO OUT ×1

Mach series control system improves the transmission of one network cable by 650,000 points to 2.2 million points ,

breaking through the bottleneck of the traditional LED control system transmission.It simplifies the connection of LED screen and facilitates on-site wiring, saving time, effort and money.

Max. Load 8.8M pixel

Max. Width 8192 px, Max. Height 3840 px, support customize.

The single machine supports six layers of screens, meeting the multi-screen display requirements

Support cut switching between single input sources, no flashing, no black screen
