FW16-C Mach Series

LED Video Controller

FW16-C

Rich input/output

Input：HDMI2.0x1， DP1.2x1，12G SDIx1，DVIx4，OPTx4，Genlock (in)x1

Output：Ethernet portx16 OPTx2 HDMI LOOPx1 HDMIx1 Genlock (out)x1

2.2 Million Pixels Per 1G Cable

Mach series control system improves the transmission of one network cable by 650,000 points to 2.2 million points ,

breaking through the bottleneck of the traditional LED control system transmission.It simplifies the connection of LED screen and facilitates on-site wiring, saving time, effort and money.

The whole machine is 8 main and 8 standby, The whole machine loading up to 17.6M

Single controller integrates main and backup network cable output into an all-in-one machine, which improves the reliability of on-site activities and greatly saves the cost of equipment and long lan cables.

10G optical ports inputs/outputs

4 Layers Seamless Switching

Supports multi-machine splicing

Support multi-machine cascade splicing, easily control large resolution LED screen.

Support interconnection with OPT port of V16 / V12

Support optical fiber interconnection with V16, V12, EC90 and other equipment, making signal transmission more stable and farther, and more cost-effective.
